iSet autoglide 5 | Travel: 10 - 60m

Energy chain system: autoglide 5

Complete set includes:
chain links, separators, track holder for AG, upper run guide, moving end mounting brackets, fixed end mounting brackets, wire rope, rope tensioning unit, fixed end module, screwdriver

Dimensions:
Inner height: 25mm
Travel: 10 - 60m
Inner width: 77mm
Bend radius: 75 - 150mm

Applications:
intralogistics, crane systems, alternative to busbar systems, storage and retrieval units, mini-loads, material handling

Shop

Assembly instructions

Parts list

Example: PACK.2400.07AG5.075.10000.01 | Travel: 10m | Bend radius 75mm

Designation	Example pictures	Part number	Quantity
Individual parts AG5		2400.07AG5.075.0	110 chain links
Individual parts AG		2400.07AG.075.0	109 chain links
Turned chain links		2500.07.075.0	2 chain links
Standard chain links		2400.07.075.0	2 chain links
Mounting brackets for moving end Mounting brackets for fixed end		2070.3PZB.A2 2070.4PZ.A2	1 piece 1 piece
Separators		AG.25.2.1	122 pieces
Wire rope		AG5.SEIL.10	11m
Rope fastening Rope tensioning unit Track holder for AG		AG5.BEF.05 AG5.BEF.1 AG5.2400.07	1 piece 1 piece 28 pieces
Fixed end module		AG5.FP.2400.07	1 piece
Upper run guide		2400.07AG5.075.OF.0	4 pieces
Support plate		919.455	0
Screwdriver		MAT0050145	1 piece

Features and benefits

Supply energy over long distances cost-effectively. The autoglide 5 energy chain system is specifically designed for horizontal use in intralogistics and on crane systems. The energy supply system is quick to install, since it requires no guide trough. Instead, it lies on a steel wire rope held in place by the e-chain contour.

Assembly times 88% shorter than those for the conventional standard solution with guide troughs
Energy, data, air and liquids in ONE system
Often saves two or more other systems needed for transmitting data
4m/s speed
Quiet operation: 63db(A) at 2m/s
50% floor remains free, no guide trough needed

⬤⬤⬤⬤⬤ = completely
⬤⭘⭘⭘⭘ = not at all

Quick assembly	⬤⬤⭘⭘⭘
Cost-effective	⬤⬤⭘⭘⭘
Little space required	⬤⬤⬤⭘⭘
High modularity	⬤⭘⭘⭘⭘
Good availability	⬤⬤⬤⭘⭘
Long travels	⬤⬤⬤⬤⭘
High-speed	⬤⬤⬤⭘⭘
High stability	⬤⬤⭘⭘⭘
Low noise level	⬤⭘⭘⭘⭘

Products that can be used with the autoglide 5

Bus cables

Bus cables

For special climatic conditions
For tight radii of up to 7.5xd
For long travels
Jacket materials: PVC, iguPUR, PUR, or TPE

Motor cables

Motor cables

Flame-retardant, oil-resistant, halogen-free
For tight radii of up to 5xd
Overall shield with optimised braid angle
Jacket materials: PVC, iguPUR, PUR, or TPE

Application example with autoglide

autoglide 5 in SRUs

The autoglide 5, an alternative to the busbar system in gliding applications with travels of up to 80 metres, is used by Kardex Mlog in storage and retrieval units. The autoglide 5's quick assembly saves the company time and money.

autoglide 5 in conveyor technology

autoglide 5 in conveyor technology

PMV Fördertechnik uses the new autoglide 5 energy chain, saving its end customers 1.5 days of installation effort.
